An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)

Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 935

An illustration from An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth, 1888, leaf 935
Fig. 9C0. iHAP. L WINDOWS. 915 he whole entablature a quarter of its height, and the architrave one sixth of the width)f the aperture. Tlie face of the pilasters or columns at the sides^ must be regulated)y the lower fascia of the architrave, and their breadth is to be a semidiameter. 2741. Fig.…
