An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)

Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 974

An illustration from An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth, 1888, leaf 974
t 3^inches, and the upper 1 foot 11 j-^ inches, giving a mean of 2 feet \{^ inches; their collecteddiameters are 12 feet 9 inches, whilst that of the intercolumniations at the s.ame level is 23feet Ifj inches, nearly double the space occupied by the columns. The height of the en-tablature without… … Fig. 1040. IONIC HEXASTYLE TEMPLES. supposing the tympanum to rise a ninth of its base ; the height of the columns is 21 feet7i inches, and their united mean diameter 12 feet 9 inches, which being multiplied togetherproduce 275 feet 8 inches, or nearly equivalent to the area of the mass they…
