Bridges, structural steel work, and mechanical engineering productions (1909)
Sir William Arrol and Company, Ltd · Sir William Arrol and Company, Ltd · leaf 306
.- ( 259 ) Hydraulic Angle=Cutting Machine. rilHE illustration on this ]>age shows a simple and effectiv-*- hydraulic machine for eutthm angles for ship and brider ee … Cutting Bars and Angles for Girders building. The shear is secured to a ram working in acylinder, controlled by a simple form of valve. The anglerests on the anvil, which carries dies to suit the shape.I|v changing the dies, any form or dimension of bar maybe cut. so that the tool lias a wide range…
