Collection of United States patents granted to Thomas A. Edison, 1869-1884 (1869)
Edison, Thomas A. (Thomas Alva), 1847-1931, Peters, N. (Norris), lithographer, Hammer, William Joseph, 1858-1934, former owner. DSI, Edison, Thomas A. (Thomas Alva), 1847-1931, inscriber. DSI, United States. Patent Office · Washington, D.C. : U.S. Patent Office · leaf 703
N. PETCBS. Pholo-Lilhographor, Waihingfcxl D. C United States Patent Office, THOMAS A. EDISON, OF MENLO PAEK, NEW JERSEY, ASSIGNOR TO WESTERNUNION TELEGRAPH COMPANY, OF NEW YORK, N. Y. IMPROVEMENT IN CARBON-TELEPHONES. Specification forming part of Letters Patent No. 222,390, dated December 9,1879;…
Trade catalogs · Patents · Edison, Thomas A. (Thomas Alva), 1847-1931 · Inventions · Telegraph · Electric machinery · Electric apparatus and appliances · Phonograph · Telephone · Motors
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
