Detrick arches showing their adaptability to all types of boilers and stokers, special furnaces and oil stills (1921)
M.H. Detrick Company. · M.H. Detrick Co. · leaf 39
ARCHES Plan and Section of ArchInstallation Over a LargeDutch Oven and Super-Heater Used in Oil Refin-eriesNote Large Area Coveredby Arch … _Building materials · Masonry · Refractory masonry · Flat arch
Internet Archive · Building Technology Heritage Library · Public Domain Mark 1.0. Free to use for anything.
