Grey, C. G. (Charles Grey), 1875-1953 · London, "The Aero" · leaf 16
I. Upper main plane. 2. Lower main plane. 3. Ailerons. 4. Elevators,which also act independently as ailerons, or stabilisers. 5. Front rudder, whichmay be used in conjunction with rear rudders, or may be fixed as a cut-windonly. 6. Rear rudders. -7. Radiators. 8. Tail (sometimes a tail is… … I. Llpper main plane. 2. Lower main plane. 3. Aileron?. 4. Biplane tail.5. Twin rudders, for horizontal steering. 6. Elevators. 7. Combined wheelsfor starting and skids for landing. 8. Small tail wheels. 13 FLYING. CHAPTER I. The Sport of the Future. WHETHER one regards flying as the most…
Airplanes
