Fig. 9. 70 COMMON-SENSE IIANDRAILING Fig. 9 to show more clear-ly how the bevel for thelower pitch is obtained. Fig. 11 is the plan of arail for a level landing,the risers landing andstarting in the springingof the well. Draw thecenter line of rail and thejoint line CD. Draw thetangent lines AB and…
