Grates and fireplace fixtures in iron and brass (1907)
Drake Marble and Tile Company · Drake Marble and Tile Co. · leaf 5
r Direct Damper. 3. Down Draft Damper. {> 4. Top Tile. 5 & G. Anchor Irons holding top ™tile. 7. Outside Basket, 8. Inside Basket. 9. Ash space between bas-kets. 10. Ash Screen or CrownPiece. 11. Shaker Bottom, 12. Side Fire Tile. 13. Back Fire Tile. 14. Down Draft Flue. 15. Shell to down… … Sectional View of The New Monarch, showing down draft flue, curved tile top and top dampers.
