Part of class in carpentry work at a manual training school building stairs for their new building. 30 HOW TO READ PLANS … St a3| - Z M ft£ HOW TO READ PLANS 31 CHAPTER IX. PLUMBING AND HEATING Besides the plan showing the location of theplumbing fixtures in bathroom, kitchen, etc., it is-customary for the architect to show a PlumbingSection/ this is a diagram of the drainage andventing, but this does not show the…
