How to read plans and take off bills of materials. (1917)
William A. Radford · Radford Architectural Company · leaf 41
., are frequently left off;in cases of this kind the workman must use his ownjudgment about centering the windows and doors. Fig. 107 shows the second-floor plan; this does notpresent anything new that will not be readily under-stood if the previous pages have been studied.Locating the Windows. No… … Fig. 110—Perspective view of house illustrated in Figs. 99 to 110. MISTAKES IN READING PLANS 43 The roof lines are all shown on this plan in dottedlines, as this not only saves a separate plan, butshows the relation of the windows, partitions, etc.,to the ridges and valleys. This is much better…
