How to read plans and take off bills of materials. (1917)
William A. Radford · Radford Architectural Company · leaf 53
e to carry outsatisfactorily. An example of this from a detailsheet of a set of plans which recently came to ourattention is shown in Fig. 156. Rectifying the Back Band. Measuring the distance X of the back band wefind that it is more than the distance A of thefillet of head .casing; therefore with… … to the owner he decided to use a mitre trim, as hewanted the back band trim, but we suggested thathe get the effect of the cabinet trim by using a littlecrown mould on the top as shown in Fig. 157. In a case like the above do not simply say that itwould not work out or cant be done/ etc., but…
Building materials, house plans · House contruction · Lumber
