How to read plans and take off bills of materials. (1917)
William A. Radford · Radford Architectural Company · leaf 8
Fig. 23—Plan, elevation and side view of rectangular block withboth sides beveled; resembling a house with gable roof, the East Elevation, etc. If the building occupiesan entire square or block, or runs thru from streetto street, the elevations may be marked MainStreet Elevation or Elevation on…
Building materials, house plans · House contruction · Lumber
