s are all rectangular in form. Importance of Careful Reading. To show the importance of always looking atevery view, suppose that one side of the stone blockwas beveled off for about a half of its depth, theworking drawing in this case would be like Fig. 22.It would be noticed that the front… … Fig. 24—Plan, elevation and side view of rectangular block withtop beveled on four sides; resembles a house with hip roof. A house of rectangular shape and a flat roofwould be shown on a drawing like Fig. 21; if it hada lean-to roof, Fig. 22 would show its outline. Fora house with a pitched roof…
