Illustrated catalogue of galvanized iron roofing and shedding, iron structures, &c. : patent portable steel railways, railway plant, iron bridges, &c. (1884)

A. & J. Main & Co. · A. & J. Main & Co. · leaf 5

An illustration from Illustrated catalogue of galvanized iron roofing and shedding, iron structures, &c. : patent portable steel railways, railway plant, iron bridges, &c., 1884, leaf 5
SECTION No. 7.—Suitable for Spans of 35 to 45 feet. .-->■ … SECTION No. 8.—Suitable for Spans of 45 to 60 feet, shewing Curved Ventilator, with LouvreBoards, which may be used with any of the foregoing Sections. Galvanized Iron Roofing- and Structures. 3 TRUSSED IRON ROOFING, Ridged Sections. The distinctive feature of Trussed Roofing is that Iron…

Roofing · Sheet roofing · Corrugated roofing · Sheet metal · Structural iron · Ironwork

Internet Archive · Building Technology Heritage Library · Public Domain Mark 1.0. Free to use for anything.
