sideetothenot Figure IV.Three-wire Meter. (Hij»li Emcieiicy Type).Connect the outside wires from the mains to the outsideterminals of the meter, being sure to connect the positive side tothe terminal marked +. Connect the outside wires from thelamps to the inside terminals of the meter. Connect, by… … l^riiiiary M<*t<M\ ^ Connect tlic nuter hy means of the two outside terniinais inseries with one side of the jjrimary circuit. Conntrct the terminals/ of the small transformer across the primary mains, and theterminals .Sto the two small terminals of the meter. The proper direction of…
