Pressure distribution on wing ribs of the VE-7 and TS airplanes in flight (1927)

NASA Technical Reports Server (NTRS) · leaf 15

An illustration from Pressure distribution on wing ribs of the VE-7 and TS airplanes in flight, 1927, leaf 15 — N.A.C.A. Technical Note No.267 Figs.5f,g,h,i … Chord line in inches Figs.5f,g,h,i Pressure distrihution.Level flight.VE-7 airplane.

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
