The Determination of Several Spray Characteristics of a High-Speed Oil Engine Injection System with an Oscilloscope (1928)
NASA Technical Reports Server (NTRS) · leaf 15
N.A.C.A. Technical Note No.298 Fig.5 o … 2000 1600 400 800 1200 Speed, R.P.M. Fig.5 Effect of engine speed on injection lag, duration of injection, and spray characteristics of an automatic, centrifugal type injection valve. Orifice diameter .025" Valve opening pressure 6000 lb./sq.in. Fuel quantity constant at 2.5 X 10-4 lb./cycle,NASA Technical Reports Server (NTRS)
Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
