Experiments with an Airfoil Model on which the Boundary Layers are Controlled Without the Use of Supplementary Equipment (1931)

NASA Technical Reports Server (NTRS) · leaf 8

An illustration from Experiments with an Airfoil Model on which the Boundary Layers are Controlled Without the Use of Supplementary Equipment, 1931, leaf 8 — o 5 strips I/I6" plywood 3/8" wide. 5 strips I/I6" plywood 3/4" ;7ide. O o Slots .005" wide .040" slot \ … Airfoil section U.S.A.~35A Span 32 inches Fig.2 Internal-circulation airfoil. 10

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
