Heat Dissipation from a Finned Cylinder at Different Fin-Plane/Air-stream Angles (1932)

NASA Technical Reports Server (NTRS) · leaf 13

An illustration from Heat Dissipation from a Finned Cylinder at Different Fin-Plane/Air-stream Angles, 1932, leaf 13 — 4 IJ.A.C.A- Technical Note No.429 Fig.2 ^Differential thermocouples 230 volts d,c< ]?ig,2 Wiring diagram of test unit, rheostats, and instnjments.

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
