The Effect of Injection-Valve Opening Pressure on Spray-Tip Penetration (1931)

NASA Technical Reports Server (NTRS) · leaf 6

An illustration from The Effect of Injection-Valve Opening Pressure on Spray-Tip Penetration, 1931, leaf 6 — 3*ig, 2, Effect of valve opening pressure on penetration. Injection pressure = 6000 lb. per sq. in.

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
