10 inches from nozzle 5 inches from nozzle 7.5 inches from nozzle Injection pressure, 100 pounds per square inch Air density, 1 atmosjihere Diameter of discharge orifice, 0.020 inch 3 99 Fig. 3 Photomicrographs showing the various stages in the hreakdown of a low-velocity fuel Jet, X 10
