Full-scale Wind-tunnel to Determine a Satisfactory Location for a Service Pitot-static Tube on a Low-wing Monoplane (1936)
NASA Technical Reports Server (NTRS) · leaf 26
Figure 19.- Fairchild 22 with Zap flap. Wing,5.21 \\(mean chord) "by 32.83 ft., N-22 section profile, rectangular (rounded tip) plan >\fora. Zap flap, chord, 1.65 ft. total flap area, 44.0 sq.ft., flap open, 8f = 59°, hinge axis atN\80 percent chord. Survey station, 0.431 semi span inboard of wing…NASA Technical Reports Server (NTRS)
Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
