Calculated effect of various types of flap on take-off over obstacles (1936)

NASA Technical Reports Server (NTRS) · leaf 18

An illustration from Calculated effect of various types of flap on take-off over obstacles, 1936, leaf 18 — Flap angle, degrees 3?igure S.-Variation of total take-off distance with flap angle for the ffowler wing.

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
