Tanks Test of a Model of the Hull of the Navy PB-1 Flying Boat - N.A.C.A. Model 52 (1936)

NASA Technical Reports Server (NTRS) · leaf 13

An illustration from Tanks Test of a Model of the Hull of the Navy PB-1 Flying Boat - N.A.C.A. Model 52, 1936, leaf 13 — Fig. 2 I.A.C.A. Technical lote Bo. 5T6 Figure 3.-Diagram* of eet-upe for free-to-trim and fixed-trim teste.

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
