The practical application of the slide valve and link motion to stationary, portable, locomotive, and marine engines : with new and simple methods for proportioning the parts (1897)
Auchincloss, William Stuart, 1842-1928 · New York : Van Nostrand · leaf 162
The subjoined dimensions will be found convenient forthe construction of a trial example, in which of course twotemplates should be employed, one to represent the link,the other the combination lever :— … WALSCIIAEET LINK MOTION. 123 Diameter of piston=18.Stroke=24 ; Connecting rod=100.Ratio=1 : 8£. Axis of link 74 from centre of sliaft and 15| above cen-tral line of motion. Eccentric rod pin 13 from axis of link.Radius of link and length of rod=42£\Link block to end centre of radius rod=6,Long…
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
