Some Characteristics of Sprays Obtained from Pintle-type Injection Nozzles (1933)
NASA Technical Reports Server (NTRS) · leaf 9
.004 • 003 .001 • 002 Time, second Spray from nozzle with 8° pintle, injection pressure 1500 lb./sq.in., Figure 3. valve opening pressure 600 lb./sq.in., chamber density 18 atmospheres … .003 .002 .001 Time, second CD Spray from nozzle with 30° pintle, injection pressure 1500 lb./sq.in.f Figure 8. valve opening pressure 600 lb./sq.in., chamber density 18 atmospheres 00NASA Technical Reports Server (NTRS)
