Discharge characteristics of a double injection-valve single-pump injection system (1937)
NASA Technical Reports Server (NTRS) · leaf 16
0 10 20 0 Pump 10 rotation, 20 dog-. 0 10 20 Injection valve 1 Injection valve 2 Summation of both valves Figure 6.- Effect of unequal valve-opening pressures on the discharge characteristics of a double-valve •? injection system. Pump speed, 750 r.p.m.; orifice diameter, 0.022 in.; throttle…NASA Technical Reports Server (NTRS)
Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
