Effects of Some Primary Variables of Rectangular Vortex Generators on the Static-pressure Rise Through a Short Diffuser (1952)

NASA Technical Reports Server (NTRS) · leaf 22

An illustration from Effects of Some Primary Variables of Rectangular Vortex Generators on the Static-pressure Rise Through a Short Diffuser, 1952, leaf 22 — NACA RM L52B13 21 … 5*1 2.85; - = 0.5; a = 15°; Figure 8. - Effect of vortex-rgeneratt>r span c = O.OO65). dl
