Armstrong Whitworth 27 "Ensign" commercial airplane (British) : an all-metal high-wing monoplane (1937)

NASA Technical Reports Server (NTRS) · leaf 9

An illustration from Armstrong Whitworth 27 "Ensign" commercial airplane (British) : an all-metal high-wing monoplane, 1937, leaf 9
N.A.C.A. Aircroft Circular No. 206 Fig.1 … Wing area «2450 Sq.ft. Span, 123 ft. Toil plane area * 402 Sq.ft. Length, HO ft. Fin i rudder area «■ 173 Sq.ft. Height, 23 ft. Figure I.-Genera/ arrangement drawing of the A.W. 27 airplane.
