Determining size of drops in fuel mixture of internal combustion engines (1926)
NASA Technical Reports Server (NTRS) · leaf 9
Figs.l & 3. N.A.C.A. Technical Memorandum No.390 … Conductor to ground 1 = Mirror galvanometer. Fig.l Arrangement for determining rm from the quantity of electricity carried away "by the drops. a=Projection &4 apparatus. b=Screen cl>c2=Farallel rays of light. dnjdgjdgjd^Mirrors, el'e2=Lenses. g=Mixture conduit with windows. h=Distribution on the…NASA Technical Reports Server (NTRS)
Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
