Pressure Distribution over the Rudder and Fin of an Airplane in Flight (1923)

NASA Technical Reports Server (NTRS) · leaf 13

An illustration from Pressure Distribution over the Rudder and Fin of an Airplane in Flight, 1923, leaf 13 — REPORT ^^ATIOKAL ADVISORY COMMITTEE FOR AERONAUTICS. … ~Rudder- -Fin- Fig. 10.—Distiibution of load in a sand test.

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
