Effects of Air-Fuel Spray and Flame Formation in a Compression-Ignition Engine (1937)

NASA Technical Reports Server (NTRS) · leaf 10

An illustration from Effects of Air-Fuel Spray and Flame Formation in a Compression-Ignition Engine, 1937, leaf 10 — Figure 8.—Enlargements of photographs of fuel sprays and first part of flame for air-fuel ratios from 25.7 to 50.5.

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
