Automatic stabilization (1936)
NASA Technical Reports Server (NTRS) · leaf 41
N.A.O.A. Technical Memorandum No. 802 Figs. 11,13,14,15 … Figure 14.-AsKania pneumatic repeater compass. (1) Transmitting compass. (3) Deviation amplifier. (3) Predetermined course indicator. (4) Venturi. or Figure 15.— Askania course T stabilizer. (l) Transmitter compass. (2; Repeater. (3) Predetermined direction indicator. J4) Nozzle. >5) Capsule with…NASA Technical Reports Server (NTRS)
Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
