Behavior of turbulent boundary layers on curved convex walls (1936)

NASA Technical Reports Server (NTRS) · leaf 20

An illustration from Behavior of turbulent boundary layers on curved convex walls, 1936, leaf 20
o … 3 figure 1.- »i to «g screens, gl honeycomb, b channel of steady flow, d cover of pressure reg- ulator, o oil damper, as regulator cover stop, p pitot tube to measure total pressure head ge in un- disturbed flow, P2 replaceable pitot tube to measure the variable total pressure head in the boundary…
