Sectional plan. ^iGS. 18 and 19.—Arrangement of air passages in Atkinson and Orossloysscavenging arrangement. 36 TYPES OF GAS ENGIJTES. but that specially long, well-fitted spindles, working in longsleeves, are sufficient to prevent escapes. The valve spindlesare always on the face subjected to the… … Fig. 20.—MuBhroom valves used iii gas engines, placed at the end of a 65 ft. length of exhaust pipe ofuniform diameter. No sudden enlargements are permissiblewithin about 65 ft. of the engine, although drain pocketsmay be inserted for the collection of condensed moisture. THE STOCKPORT GAS ENGINES.…
