Blue prints consist ofbasement plan; roof plan;floor plan; front, rear,two side elevations, wallsections and all neces-sary interior details.Specifications consist ofabout fifteen pages oftypewritten matter. Floor Plan Design No. 7086 Size: Width, 23 feet 6 inches; Length 29 feet 6 inches,… … Blue prints consist ofbasement plan; first andsecond floor plans; front,rear, and two side eleva-tions; wall sections andall necessary interior de-tails. Specifications con-sist of about twenty-pa g e s of typewrittenmatter.
