the commutator cylinder, communicate electrically with a coil, F, like that already deseribed.: The current flows from the battery, A, to the standard,'B, thence or switch, and a plunging battery. - through the shaft, C, plate, D, spring, E, coil, F, spring, G, plate, H, shaft, I, and standard, J,… … (Continued on p. 212.) while the switch © 1886 SCIENTIFIC AMERICAN, INCInternet Archive · Public domain (published before 1931). Free to use for anything.
