36 EXPERIMENTAL ELECTRICITY … Fig. 58. —Relays (M.E. S.Co.). through all of the relays is very small, they are wound with many turns of fine wireto secure sufficient mag-netic effect. The resis-tance of the relays istherefore great, beingfrom 80 to 300 ohms.The resistance of thesounder is much lessand may be anything from 5 to…
