| Entered at the Post Office of New York, N_ Y., as Second Class Matter, Copyright, 1897, by Munn & Co.) Vel, LXXVIT—No. 18.1 NEW YORK, NOVEMBER 6, 1897. $8.00 A YEAR, WEEKLY. Fig. 2.-CUTTING SLOTS IN HUB FLANGES, Fig. 1,-CHAIN, RIVETING MACHINE, Fig. 4.- CHAIN LIMBERING MACHINE, … Fig. 5. SAWING OFF CHAIN BLOCKS. Fig. 3. DRILLING HUB FLANGES Fig. 6,-HEADING THE SPOKES. pete 8 Fig, 7.-PROFILING THE SPIDER. THE PLANT OF A MODERN BICYCLE FACTORY.—{See page 292.] © 1897 SCIENTIFIC AMERICAN, INC.Internet Archive · Public domain (published before 1931). Free to use for anything.
