Greene, Charles E[zra] 1842- [from old catalog], Greene, Albert Emerson. [from old catalog] · Ann Arbor, Mich., Printed for the author · leaf 75
see Chapter VII. 73. Compound Beam.—When one beam upon which aload is imposed is supported by another, the bending momentsand shears acting upon the latter can be found by algebraicsubtraction of those resisted at corresponding sections of theformer from the moments and shears of the system as a… … Thus in Fig. 21, by XII., §69, the bending momentbetween A and E, for the combination is W^t, and between Eand F is W ((^ + ^); the shear from A to E is W, and is zeroon E F. The shear from C to E in the upper beam is W,and the moment at E is ^b. Therefore the shear in thelower beam from C to D is…
Mechanics, Applied · Strength of materials
