Fig. 243 and fig. 244 exhibit the method of grindingthe sides of a face, or straddle mill, by means of the The Advanced Machinist. 221 GRINDING OPERATIONS. … emery wheel. The straddle mill is placed upon the table ofthe grinding machine, and is revolved on a stud, so as tobring each tooth in turn under the action of the revolvingemery wheel. Fig. 246.
