The advanced machinist; a practical and educational treatise, with illustrations (1903)
Hawkins, Nehemiah, 1833- · New York, T. Audel · leaf 240
e stop rod Jt which slides through the vise block, andthe stops K K, being set to the length of the screw to becut, are operated by contact with the vise. The Advanced Machinist. 237 MACHINE BOI/T CUTTING. The driving cone L, with pinion M, gear into wheel Non the live spindle; the oil supply O is… … Fig. 254. The pump is of ample size, so that when running onthe slow speed a sufficient supply of oil is discharged hitcthe oil-pot to keep a constant stream on the dies whencutting threads; the removable chip-pan will hold the chipsof a days work. 238 The Advanced Machinist. MACHINE BOI/T CUTTING.…
