Aeroplane construction and operation; including notes on aeroplane design and aerodynamic calculation, materials, etc. A comprehensive illustrated manual of instruction for aeroplane constructors, aviators, aero-mechanics, flight officers and students. Adapted either for schools or home study (1918)
Rathbun, John B · Chicago : Stanton and Van Vliet Co. · leaf 122
Fig. 8. Pressure Distribution for Thin Circular Section,the Effect of Increasing the Camber. (Eiffel) … Fig. 9. Shows angles where the turbulence formed a greater percentageof the total drag. Figs. 8, 9, 10, 11, 12 are pressure distribution curvestaken along the section of several aerofoil surfaces. Theseare due to Eiffel. In Fig. 8 is the pressure curve for athin circular aerofoil section, the depth…
Airplanes
