Aeroplane construction and operation; including notes on aeroplane design and aerodynamic calculation, materials, etc. A comprehensive illustrated manual of instruction for aeroplane constructors, aviators, aero-mechanics, flight officers and students. Adapted either for schools or home study (1918)
Rathbun, John B · Chicago : Stanton and Van Vliet Co. · leaf 194
on the Rear Wings of a Tandem Pai direction of the flow. If the front wings are at an incidenceof (i) degrees (Fig. 11), the deviation or washdown ofthe air stream to the rear will be expressed by : d= (0.5i+1). If i = incidence of rear wing measured from the … Kig. 1 -• T^if^ei? Arrangements Used in Eiffel Experimentsm Straight Line, (2) Rear Wing at 2.5% (3) Rear Wi (1) Chord;ing at 5. chord of the front wing, then the angle of incidence madeby the rear chord to the horizontal will be: I = (i-i)— (0.5i-f 1), where I is the incidence of the rear plane…
Airplanes
