Fig. 155. Westinghouse Single-Phase Uni-Coil Armature Complete … Fig. 156. Westinghouse Single-Phase Armature Core and Coils. Distributed Winding Fig. 157. Westinghouse Single-Phase Distributed Winding Armature Complete Westinghouse Armature with Distributed Winding. Figs. 156and 157 show a single-phase Westinghouse alternator armature withdistributed winding.…
