Hartford Steam Boiler Inspection and Insurance Company · Hartford, Ct. : Hartford Steam Boiler Inspection and Insurance Co · leaf 56
olumn ofwater 2.4 feet high (at the temperature corresponding to 60 pounds pressure) to give astatic pressure of 1 pound per square inch. The height of a column that would give astatic pressure of 60 pounds would therefore be 60x2.4 = 144 feet. To find the weight of water in the pipe, we multiply… … Fig. 2.—Illustrating the Water Ram in Blow-off Pipes. one pound. The area of a 3-inch circle is 7.07 square inches, and the distance from theboiler to the blow-cock, in the present case, is 66 inches. Hence the volume of the pipeis 66x7.07=467 cubic inches (in round numbers). Taking the density of…
Locomotives · Steam-boiler explosions
Internet Archive · Carnegie Library of Pittsburgh · Public Domain Mark 1.0. Free to use for anything.
