Fig. 328. Squirrel-Cage Rotor Mountedin Ordinary Four-Pole Field Fig. 329. Diagram of Four-Pole Two-Phase Induction Motor of which on the rotor is the same as the action of an ordinary fieldmagnet mechanically revolved. Thus Fig. 328 shows a squirrel-cage rotor A surrounded by an ordinary field…
