Verrill, A. Hyatt (Alpheus Hyatt), 1871-1954 · New York, Dodd, Mead and company · leaf 80
e cut in each piece and a squaredowel driven in as shown at Fig. lib. A bettermethod is to cut the timbers as shown in Fig. 12and use either a peg or a square dowel as indi-cated at Fig. 12a. Still another method is shownat Figs. 13 and 13a; while by cutting the timbersas indicated in Fig. 14 the… … Fig. 8 Fig. 9
Carpentry
