The American architect : comprising original designs of cheap country and village residences, with details, specifications, plans and directions, and an estimate of the cost of each design (1849)
Ritch, John W. (John Warren), b. 1822 · New York : C. M. Saxton · leaf 102
FfsATH 80. … PLATE LXXXI.PERSPECTIVE VIEWS. PLATE LXXXILFRONT AND END ELEVATIONS. PLATE LXXXIII.PLAN OF FIRST STORY AND ATTIC. PLATE LXXXIV. Details.—Fig. 1. Shows the Gable and Turret.—Fig. 2. Shows the manner of constructing the gutter. Athe rafter ; a a a a the hemlock strips ; b the eave board. B the plate.…
Architecture, Domestic
