The American builder's companion : or, A system of architecture, particularly adapted to the present style of building ; illustrated with seventy copperplate engravings (1827)

Benjamin, Asher, 1773-1845 · Boston : R.P.&C. Williams · leaf 48

An illustration from The American builder's companion : or, A system of architecture, particularly adapted to the present style of building ; illustrated with seventy copperplate engravings, 1827, leaf 48 — a ; divide d a, d b, b f, and a g, each into a likenumber of equal parts ; from the point e, and through the points I, 2, 3, in a gand bf, draw lines ; also from c, through the points \,2,3, in d a and d b, drawlines, cutting the former at the points 4, 5, 6, and 7, 8, 9, through which pointsthe…

Architecture · Architecture -- United States

Internet Archive · New York Public Library · Public Domain Mark 1.0. Free to use for anything.
